Slim Fiberscope Series
Buy Now
The images are large, bright and clear. The 100 ‘ angel of view and 24X eyepiece enhance orientation and help eliminate blind spots. A simplified lightweight design incorporates traditional high quality optics. Ease of introduction is enhanced by the combination of an at traumatic insertion tube with specially designed flexibility characteristics. The OLYMPUS cold light source system is compatible with this fiberscope.
High Resolution Optics System
New Shape Control Section
Special Insertion Tube Flexibility
Good Compatibility
| Angel of View | 100° |
| Direction of observation | 0° Straight |
| Depth of Field | 3 ~ 100mm |
| Outer Diameter of insertion Tube | φ5.0mm |
| Range of Tip Bending | Upto 180° , Down 90° |
| Inner Diameter of Biopsy Channel | φ2.0 mm |
| Working Length | 550mm |
| Total Length | 870mm |
| Angel of View | 100° |
| Direction of observation | 0° Straight |
| Depth of Field | 3 ~ 100mm |
| Outer Diameter of insertion Tube | φ5.0mm |
| Range of Tip Bending | Upto 180° , Down 90° |
| Inner Diameter of Biopsy Channel | φ2.0 mm |
| Working Length | 420mm |
| Total Length | 750mm |
| Angel of View | 100° |
| Direction of observation | 0° Straight |
| Depth of Field | 3 ~ 100mm |
| Outer Diameter of insertion Tube | φ5.0mm |
| Range of Tip Bending | Upto 180° , Down 90° |
| Inner Diameter of Biopsy Channel | φ2.0 mm |
| Working Length | 370mm |
| Total Length | 680mm |
